15L Desktop Digital Display Ultrasonic Cleaner
Scope of Application
This series ultrasonic cleaners suit schools, scientific research institutions, hospitals, chemical, pharmaceutical, food and enterprises industries such as laboratory instruments cleaning as well as the pretreatment analysis of sample object, crushing, emulsification, blending, dispersion, quick dissolution, extraction, defoaming and degassing, chemical reaction acceleration, liquid viscosity reduction, etc. Besides, they are also used for the deep cleaning of the instruments, meters, electronic components, circuit boards, semiconductor silicon wafers, magnetic materials, chromed parts, hardware, optical lenses and spare parts, audio head, fiber optic connectors, polyester filter core, spinneret, latex molds, medical apparatus and instruments, glassware, jewelry, watches and clocks parts, precision parts, bearings, oil pump nozzle and the parts in mechanical manufacture and complex geometry parts.
Features
＃ Digital display and control
＃ Industrial high Q transducers, cleaning conversion efficiency is higher
＃ No-stud welding technology, stronger ultrasonic wave cleaning performance and long service life of tank
＃ MCU-SWEEP ultrasonic generator frequency-drive, ultrasonic cleaning more uniform, more powerful
＃ MCH heating system, maximum temperature up to 80°C
＃ Digital cleaning timing within 1-30mins
＃ All stainless steel material, inner tank is made by punching SUS304 1.0mm, good corrosion resistance
＃ Whole machine noise reduction processing
＃ 2500V high voltage test to ensure the product safety
Technical parameters
| Model |
Capacity (L) |
Frequency Working (KHz) |
Ultrasonic Power (W) |
Heating Power (W) |
Timing time (mins) |
Noise reduction cover |
Valve drain |
Temperature range (°C) |
Washing basket |
Inner Tanker dimension (mm) |
Packing dimension (mm) |
Gross weight (Kg) |
| UC-4035 |
0.7 |
41±1.5 |
35 |
NO |
10-600s |
YES |
NO |
NO |
Optional |
150x83x62 |
216x160x190 |
1.3 |
| UC-4060L |
2.0 |
39±1.5 |
70 |
NO |
10-600s |
YES |
NO |
NO |
Optional |
150x135x100 |
242x227x265 |
2.6 |
| UC-4060HL |
2.0 |
39±1.5 |
70 |
100 |
10-600s |
YES |
NO |
20-80 |
Optional |
150x135x100 |
242x227x275 |
2.7 |
| UC-4120 |
3.2 |
39±1.5 |
120 |
100 |
1-99min |
YES |
NO |
20-80 |
Optional |
240x135x100 |
342x240x310 |
4.77 |
| UC-4120L |
5.0 |
39±1.5 |
120 |
200 |
1-99min |
YES |
NO |
20-80 |
Optional |
240x135x150 |
342x240x355 |
5.4 |
| UC-4180 |
4.5 |
39±1.5 |
180 |
200 |
1-99min |
YES |
NO |
20-80 |
Optional |
300x150x100 |
402x252x311 |
5.65 |
| UC-4180L |
6.8 |
39±1.5 |
180 |
300 |
1-99min |
YES |
NO |
20-80 |
Optional |
300x150x150 |
402x252x355 |
6.2 |
| UC-4240L |
11 |
39±1.5 |
240 |
400 |
1-99min |
YES |
YES |
20-80 |
Optional |
300x240x150 |
412x357x380 |
8.5 |
| UC-4360 |
15 |
39±1.5 |
360 |
500(220V) 400(110V) |
1-99min |
YES |
YES |
20-80 |
Optional |
330x300x150 |
472x437x470 |
11.5 |
| UC-4360L |
20 |
39±1.5 |
360 |
500(220V) 400(110V) |
1-99min |
YES |
YES |
20-80 |
Optional |
330x300x200 |
472x437x470 |
12.5 |
| UC-4480 |
22 |
39±1.5 |
480 |
600(220V) 500(110V) |
1-99min |
YES |
YES |
20-80 |
Optional |
500x300x150 |
657x454x430 |
14.5 |
| UC-4600 |
30 |
39±1.5 |
600 |
600(220V) 500(110V) |
1-99min |
YES |
YES |
20-80 |
Optional |
500x300x200 |
657x450x475 |
16.0 |
| UC-4600T |
30 |
27±1.5 |
600 |
600(220V) 500(110V |
1-99min |
YES |
YES |
20-80 |
Optional |
490x290x195 |
657x450x475 |
20.7 |
*Voltage: 220V±10% 50/60Hz 110V±10% 50/60HZ
|
